Jet 322830 230-Volt 3-Hp 1-Phase Geared Head Bench Lathe

Jet 322830 230-Volt 3-HP 1-Phase Geared Head Bench Lathe – Precision Power Tool for Woodworking

Original price was: $518.00.Current price is: $94.99.

The Jet 322830 Bench Lathe features a powerful 3-HP motor and 230-Volt operation, delivering consistent performance for precision woodworking tasks.
Equipped with a geared head design, this lathe ensures smooth and accurate adjustments, making it ideal for both beginners and professionals.
Built with durability in mind, the Jet 322830 is constructed from high-quality materials, ensuring long-lasting performance in demanding workshop environments.
Enjoy hassle-free setup and operation with user-friendly controls and a compact bench-top design that fits seamlessly into any workspace.
Jet is a trusted brand in the power tools industry, and this lathe comes with a reliable warranty, secure payment options, and fast, efficient shipping.

SKU: lathes-2612710015094 Categories: Lathes, Power Tools, Tools & Equipment Tags: 240v, Dropship, LTL, Power, Tools & Equipment

Elevate Your Shopping Experience
Quality You Can Count On
Your Security is Our Promise
Safe Payments for a Better Shopping Experience

Description
Reviews (0)

Features

V-way bed design is induction hardened and ground
Splined, not keyed, shafts are utilized
D1-4 spindle is precision ground for accuracy and supported by high quality tapered roller bearings
Independent leadscrew and feed rod
Adjustable gibs are incorporated in the carriage and slideways
Safety on/off switch
Emergency Stop within easy reach of the Operator
Electronic Chuck Key Docking Station
Chuck Guard
Foot Brake
Gearbox provides larger threading and feed capabilities with no gear changes
Spindle actuation control is apron mounted
Gap bed section provided for larger diameter work
Inch-metric dials are standard
Compound and cross slide have backlash elimination
Tailstock may be offset for turning tapers and includes an inch-metric graduated quill
Front removable chip tray
Spindle jog button for easy gear engagement and spindle inching
Coolant system
Full length splash guard

What’s in The Box

14-Inch x 40-Inch Geared Head Lathe
Owner’s Manual

Warranty

2-Year Limited Factory Warranty
30 Day Satisfaction Guaranteed

Specifications

Sku	322830
Model	GH-1440-1
Brand	Jet
Voltage	230v
Horsepower	3 Hp
Phase	1-Phase
Swing Over Bed	14 in.
Swing Over Cross Slide	8-1/5 in.
Swing Through Gap	20 in.
Length of Gap	9-3/8 in.
Distance Between Centers	40 in.
Spindle Bore	1-1/2 in.
Spindle Mount	D1-4
Spindle Taper w/ Sleeve	MT-5
Number of Spindle Speeds	12
Range of Spindle Speeds	40 Rpm – 1,800 Rpm
Number of Longitudinal and Cross Feed Rates	40
Range of Longitudinal Feeds	0.012 Ipr – 0.0103 Ipr
Number of Inch Threads	40
Range of Inch Threads	4 Tpi – 112 Tpi
Number of Metric Threads	23
Range of Metric threads	0.45 – 7.5
Max Tool Size	5/8 in. x 5/8 in.
Compound Slide Travel	3-1/2 in.
Cross slide Travel	6-3/8 in.
Carriage Travel	37-1/2 in.
Tailstock Spindle Travel	4-3/4 in.
Taper in Tailstock Spindle	MT-3
Follow Rest Capacity	2-5/8 in.
Steady Rest Capacity	3-1/2 in.
Width of Bed	10-1/5 in.
Length	74-4/5 in.
Width	28 in.
Height	46 in.
Product Weight	2,336 lbs.
